2020 Bombtrack
Beyond+
A steel frame gravel bike with upper mid-range components and hydraulic disc brakes.
Compare the full range
| Weight | 30.4 lbs |
|---|---|
| Frame | Steel |
| Suspension | Rigid |
| Fork | Steel |
| Wheels | 650b Aluminum |
| Drivetrain | 1 × 12 |
| Groupset | NX Eagle, Truvativ Stylo |
| Brakes | Hydraulic Disc |
For This Bike
5'2" – 5'8"
5'6" – 5'11"
5'10" – 6'3"
6'1" – 6'7"
🐐 Estimated
None yet.
Do you have this bike? Help other riders make a decision about which size will work for them by sharing your own size and fit notes.
Aug 2019 · Cass Gilbert
2020 sees a few tweaks to Bombtrack's big-wheeled Beyond+ ADV, including three-pack cage mounts on each seatstay. Here are all the details, the full build kit, and a few thoughts on how it rides.
Feb 2019
The Beyond+ ADV is the most extreme of the Bombtrack ‘Beyond’ adventure series of bikes, with super fat 3" tyres on broad 29" rims double butted steel frame with a carbon fork and the much-discussed Jones Loop bar for front end control. The fat 29x3” tyres that will make light work of most off-road conditions you might find yourself in and proved a surprisingly fun bike to ride. How to go bikepacking: A beginner's guide to getting started The best gravel and adventure bikes you can buy for under £1000 Can you spend a night in the hills and still make it to work on time?
| Frame | 4130 double butted crmo tubing, with cage, rack and fender mounts, replaceable hanger, boost spacing, stealth dropper ready, 73 mm BSA shell BB Standard: BSA, 73mm, Threaded Tire Clearance: 3" |
|---|---|
| Fork | BOMBTRACK BPS 4130 crmo disc fork, tapered double butted blades, 1.1/2" - 1.1/8" tapered steerer, with fender / rack / triple cage mounts |
| Bottom Bracket | SRAM DUB BSA 73 mm |
| Headset | FSA ORBIT ITA sealed semi integrated / external aheadset, 1.1/2" - 1.1/8" |
| Stem | BOMBTRACK TRAMP forged aluminum stem, 3° |
| Handlebar | BOMBTRACK TRAIL flat bar, 31.8 mm, 5° rise, 8° backsweep |
| Saddle | BOMBTRACK ORIGIN saddle |
| Seatpost | BOMBTRACK YEW aluminum seatpost, 30.9 mm x 400 mm Type: Rigid |
| Pedals | - |
| Grips | BOMBTRACK LOCK 145 mm grips |
| Rear Derailleur | SRAM NX EAGLE rear derailleur, clutch, long cage |
|---|---|
| Front Derailleur | - |
| Crank | TRUVATIV STYLO 6K aluminum crank, Boost DUB, SRAM NX EAGLE steel, narrow-wide, 30T, 1/2" x 11/128" |
| Shifters | SRAM NX-EAGLE 12-speed trigger shifter |
| Cassette | SRAM PG-1230 EAGLE 12-speed cassette, 11-50T |
| Chain | SRAM NX EAGLE chain, 1/2" x 11/128", 118L |
| Brakes | SRAM LEVEL hydraulic disc brakes with 180 mm F / 160 mm R rotors Type: Hydraulic Disc |
| Rims | Front: WTB ST i35 double wall, TCS 2.0, 32h, Rear: WTB ST i35 double wall, TCS 2.0, 32h |
|---|---|
| Front Hub | Front: BOMBTRACK TRAIL sealed hub, 6-bolt disc, 15 x 110 mm thru-axle, Rear: BOMBTRACK TRAIL sealed hub, cassette, 6-bolt disc, 12 x 148 mm thru-axle |
| Rear Hub | Front: BOMBTRACK TRAIL sealed hub, 6-bolt disc, 15 x 110 mm thru-axle, Rear: BOMBTRACK TRAIL sealed hub, cassette, 6-bolt disc, 12 x 148 mm thru-axle |
| Tires | Front: WTB RANGER TCS Tough folding tire 27.5" x 2.8", Rear: WTB RANGER TCS Tough folding tire 27.5" x 2.8" |
| Lights | - |
|---|---|
| Fenders | - |
| Racks | - |
