Beyond+ 1
A steel frame gravel bike with upper mid-range components and hydraulic disc brakes.
Compare the full range
Weight | 31.1 lbs |
---|---|
Frame | Steel |
Suspension | Rigid |
Fork | Steel |
Wheels | 650b Aluminum |
Drivetrain | 1 × 12 |
Groupset | NX Eagle, Truvativ Stylo |
Brakes | Hydraulic Disc |
For This Bike
Aug 2019 · Cass Gilbert
2020 sees a few tweaks to Bombtrack's big-wheeled Beyond+ ADV, including three-pack cage mounts on each seatstay. Here are all the details, the full build kit, and a few thoughts on how it rides.
Jun 2018
Bombtrack's Beyond+ is a machine made for fully laden exploring, with a steel frame and fork that are covered in mounts and fat 2.8" tyres that take the sting out of the trail. It's certainly competent at that but it's also good fun when you leave the bags at home and just go ride. How to go bikepacking: A beginner's guide to getting started The best gravel and adventure bikes you can buy for under £1000 Can you spend a night in the hills and still make it to work on time?
Frame | 4130 double butted crmo tubing, with cage, rack and fender mounts, replaceable hanger, boost spacing, stealth dropper ready, 73 mm BSA shell BB Standard: BSA, 73mm, Threaded Tire Clearance: 3.5" |
---|---|
Fork | BOMBTRACK BPS 4130 crmo disc fork, tapered double butted blades, 1.1/2" - 1.1/8" tapered steerer, with fender / rack / triple cage mounts |
Bottom Bracket | SRAM GXP DUB 73 mm |
Headset | FSA ORBIT ITA sealed semi integrated / external aheadset, 1.1/2" - 1.1/8" |
Stem | BOMBTRACK TRAMP forged alloy stem, 3° |
Handlebar | BOMBTRACK TRAIL flat bar, 31.8 mm, 5° rise, 8° backsweep |
Saddle | BOMBTRACK ORIGIN saddle |
Seatpost | BOMBTRACK YEW alloy seatpost, 30.9 mm x 400 mm Type: Rigid |
Pedals | - |
Grips | BOMBTRACK LOCK 145 mm grips |
Rear Derailleur | SRAM NX EAGLE rear derailleur, long cage |
---|---|
Front Derailleur | - |
Crank | TRUVATIV STYLO 6K alloy crank, Boost DUB, SRAM X-SYNC Eagle steel, narrow-wide, 30T, 1/2" x 11/128" |
Shifters | SRAM NX-EAGLE 12-speed trigger shifter |
Cassette | SRAM PG-1230 Eagle 12-speed cassette, 11-50T |
Chain | SRAM NX EAGLE chain, 1/2" x 11/128", 118L |
Brakes | SRAM LEVEL hydraulic disc brakes with 180 mm F / 160 mm R rotors Type: Hydraulic Disc |
Rims | Front: WTB ST i35 TCS 2.0 double wall sleeved, 32h, Rear: WTB ST i35 TCS 2.0 double wall sleeved, 32h |
---|---|
Front Hub | Front: BOMBTRACK TRAIL sealed hub, 6-bolt disc, 15 x 110 mm thru-axle, Rear: BOMBTRACK TRAIL sealed hub, cassette, 6-bolt disc, 12 x 148 mm thru-axle |
Rear Hub | Front: BOMBTRACK TRAIL sealed hub, 6-bolt disc, 15 x 110 mm thru-axle, Rear: BOMBTRACK TRAIL sealed hub, cassette, 6-bolt disc, 12 x 148 mm thru-axle |
Tires | Front: WTB TRAILBLAZER TCS LIGHT folding tire, 27.5" x 2.8", Rear: WTB TRAILBLAZER TCS LIGHT folding tire, 27.5" x 2.8" |
Lights | - |
---|---|
Fenders | - |
Racks | - |
