2019 Bombtrack
Arise Tour
A steel frame gravel bike with upper mid-range components and mechanical disc brakes.
Compare the full range
| Weight | 30.9 lbs |
|---|---|
| Frame | Steel |
| Suspension | Rigid |
| Fork | Steel |
| Wheels | 700c Aluminum |
| Drivetrain | 2 × 10 |
| Groupset | Deore, Tiagra |
| Brakes | Mechanical Disc |
For This Bike
5'1" – 5'6"
5'4" – 5'9"
5'7" – 6'0"
5'10" – 6'3"
6'0" – 6'5"
🐐 Estimated
None yet.
Do you have this bike? Help other riders make a decision about which size will work for them by sharing your own size and fit notes.
Feb 2018 · Joseph Delves
Practical and steady on the road and lively off it, the Arise 1 is light, fast, versatile and fun
| Frame | 4130 double butted crmo frame, replaceable hanger, rack / fender mounts, 68 mm BSA shell BB Standard: BSA, 68mm, Threaded Tire Clearance: 40c |
|---|---|
| Fork | 4130 crmo, tapered double butted blades with fender / rack mounts, internal hub dynamo cable routing |
| Bottom Bracket | FSA MEGA EXO 19 BSA |
| Headset | FSA ORBIT MX sealed external aheadset, 1.1/8" |
| Stem | BOMBTRACK ROAM forged alloy stem, -7° |
| Handlebar | BOMBTRACK CX-10 drop bar, 31.8 mm, 10° flare |
| Saddle | BOMBTRACK ORIGIN saddle |
| Seatpost | BOMBTRACK CEDAR alloy seatpost, 27.2 mm x 300 mm Type: Rigid |
| Pedals | WELLGO B109N flat pedal |
| Grips | BOMBTRACK CONTROL bar tape |
| Rear Derailleur | SHIMANO DEORE RD-M6000-SGS rear derailleur, clutch, long cage |
|---|---|
| Front Derailleur | SHIMANO TIAGRA FD-4700-B front derailleur |
| Crank | FSA OMEGA MEGA EXO 19 alloy crank, FSA OMEGA, alloy, subcompact, 46/30T, 1/2" x 11/128" |
| Shifters | MICROSHIFT BS-M10 bar end shifter 2 x 10 |
| Cassette | SUNRACE CSMS2 10-speed, 11-36T |
| Chain | KMC X10EL chain, 1/2" x 11/128", 114L |
| Brakes | TRP SPYRE C post mount mechanic disc brakes with 160 mm rotors Type: Mechanical Disc |
| Rims | Front: BOMBTRACK XCD22 double wall, i19, 36h, Rear: BOMBTRACK XCD22 double wall, i19, 36h |
|---|---|
| Front Hub | Front: KT dynamo hub, 6-bolt disc, QR axle, Rear: BOMBTRACK TITLE-DISC sealed hub, 11-speed, 6-bolt disc, QR axle |
| Rear Hub | Front: KT dynamo hub, 6-bolt disc, QR axle, Rear: BOMBTRACK TITLE-DISC sealed hub, 11-speed, 6-bolt disc, QR axle |
| Tires | Front: KENDA KWIK TENDRIL tire, 700C x 35C, Rear: KENDA KWIK TENDRIL tire, 700C x 35C |
| Lights | SUPERNOVA E3 PURE 3 front, E3 TAIL LIGHT 2 rear |
|---|---|
| Fenders | BOMBTRACK PIPE plastic fenders, 50 mm |
| Racks | TUBUS TARA front, LOGO EVO rear |
