2020 BH

ATOMX Pro-S

A 29″ aluminum frame hardtail crosscountry e-bike with upper mid-range components.

FrameAluminum
SuspensionHardtail, 100mm
ForkFox Rhythm Float 32
Wheels29″ Aluminum
Drivetrain1 × 12
GroupsetXT, SLX
MotorBrose 90Nm mid-drive
BrakesShimano SLX Hydraulic Disc
View on bhbikes.comLearn about BH
Add to Comparison
Shop with an Expert at Upway
Where to Buy
Similar Bikes
Top Comparison

View more similar bikes →

Insights
Ride Feel

Based on frame geometry and build specs.

Terrain
easyextreme
Handling
nimblestable
ATOMX Pro-S
Other Crosscountry bikes
Gearing

A bike with lower gearing will be easier to ride up steep hills, while a higher top end means it will pedal faster down hills.

Lowest gear

(climbing)

28 mph

ATOMX Pro-S

27 mph

Similar Bikes

Highest gear

(descending)

Sizing
SM

5'2" – 5'7"

MD

5'6" – 5'11"

LG

5'9" – 6'2"

🐐 Estimated

Rider Fit Notes

None yet.

Do you have this bike? Help other riders make a decision about which size will work for them by sharing your own size and fit notes.

Reviews
E-Mountainbike Magazine
First ride review: BH Bikes AtomX Carbon Lynx 6 Pro-S – Unique but is it good?

Jul 2020 · Jonas Müssig

You’ll be hard-pressed to find an eMTB with as many USPs as the BH Bikes AtomX Carbon Lynx 6 Pro-S. But is that a good or bad thing? We put it to the test.

Highs

  • Customisable support levels

  • Innovative details

  • High maximum permissible weight limit

  • Display and remote

Lows

  • Battery concept affects the entire design

  • Vario-100 mm dropper post

  • Battery handle/cover and the chain rattle

  • High centre of gravity

  • Nervous steering

Read Review

Geometry
Specs
Build
Frame

Aluminum

Fork

FOX FLOAT 32 Rhythm

Travel: 100mm

Spring Type: Air

Shock

N/A

Headset

Tapered

Stem

Race Face Ride, 35mm bar clamp

Handlebar

Race Face Ride Riser, 780mm width, 35mm clamp diameter

Saddle

Prologo Proxim 450STN

Seatpost

Race Face Ride XC

Type: Rigid

Pedals

N/A

Grips

Ergon GE10

Groupset
Rear Derailleur

Shimano Deore XT, 12-speed

Front Derailleur

N/A

Crank

FSA

Shifters

Shimano SLX, 12-speed

Cassette

Shimano SLX M7100, 12-speed, 10-51 tooth

Chain

Shimano

Chain Guide

Upper slider

Brakes

Shimano SLX, 4-piston, 200mm rotors

Type: Shimano SLX Hydraulic Disc

Brake Levers

Shimano SLX

Wheels
Rims

Alexrims EM35 TR

Spokes

Stainless steel

Front Hub

BH, MICRO SPLINE driver

Rear Hub

BH, MICRO SPLINE driver

Tires

Maxxis Rekon, EXO, TR, 120 TPI, 29" x 2.34"

Electric Components
Motor

Brose S Mag, 90Nm max torque

Battery

ATOMX, integrated, includes ILock with Smart Key bracelet

Remote

BH X-Display, 2.8" color LCD, ANT+ and Bluetooth connections; BH X-Remote control

Display

BH X-Display, 2.8" color LCD, ANT+ and Bluetooth connections; BH X-Remote control
