Released September 28
Builds
6
Price Range
$7,225–$14,000
Wheels
29″
Suspension
Full / 120mm rear, 120mm front
Frame Material
Carbon
Lightweight, fast and different.
Payson McElveen, a Texas native, relocated to Durango, Colorado, in 2012. Known as an epicenter of endurance mountain biking, he spends most of his time training there. Payson's BC40 paint scheme was inspired by the infamous and rugged San Juan mountains. A mountain range that forms the southern part of Colorado's Rocky Mountains and is touted as having some of the most diverse landscapes of any mountain range in the U.S. The beautiful but unusual hues created by the distinct geology of the San Juans influenced the colors of this actual one-of-a-kind piece of art on two wheels. When Payson first moved there, he found the mountain range incredibly intimidating, but it was the challenging terrain he needed to reach his potential as an athlete. "They've taught me enormous amounts about myself as an athlete and person. It's extraordinary to have those mountains and years of hard work reflected in this new mountain bike," said Payson.
Over two years in the making, the BC40 was designed for speed, agility, and beauty, painstakingly tested and refined on the iconic singletrack in our backyard, and made entirely here in the United States, by us, with unparalleled precision and passion. Inspired by the legendary Back 40 trail system. Meet the new BC40, a thoughtfully engineered modern cross-country machine mixed with an all-day trail sled. A plush 120mm of front and rear travel combined with a second-to-none pedaling platform and progressive geometry delivers precise speed, handling, and tracking for the needs of the modern trail shredder.
The highs and lows of this model family
MSRP | $7,225 | $7,805 | $9,730 | $10,140 | $11,770 | $14,000 |
---|---|---|---|---|---|---|
Spec Level | ||||||
Weight | 4.3 lbs (frame) | 4.3 lbs (frame) | 4.3 lbs (frame) | 4.3 lbs (frame) | 4.3 lbs (frame) | 4.3 lbs (frame) |
Fork | RockShox SID Ultimate | |||||
Wheels | Aluminum | Aluminum | Carbon | Carbon | Carbon | Carbon |
Groupset | XT | GX Eagle AXS | XTR | X01 Eagle AXS | XX1 Eagle AXS, X01 Eagle AXS | XX1 Eagle AXS |
Drivetrain | 1 × 12 | 1 × 12 Electronic | 1 × 12 | 1 × 12 Electronic | 1 × 12 Electronic | 1 × 12 Electronic |
Based on build material and quality level of the frame, fork, wheelset, groupset, suspension system, and more. Learn more →
Wheels | 29″ | 29″ | 29″ | 29″ |
---|---|---|---|---|
Stack | 593 | 604 | 617 | 628 |
Reach | 415 | 440 | 470 | 496 |
Stack/Reach Ratio | 1.43 | 1.37 | 1.31 | 1.27 |
Top Tube Length | 564 | 591 | 625 | 654 |
Seat Tube Length | 395 | 420 | 450 | 500 |
Seat Tube Angle | 76.0 | 76.0 | 76.0 | 76.0 |
Head Tube Length | 95 | 105 | 120 | 135 |
Head Tube Angle | 66.5 | 66.5 | 66.5 | 66.5 |
BB Drop | 40 | 40 | 40 | 40 |
BB Height | 334 | 334 | 334 | 334 |
Front Center | 710 | 739 | 775 | 806 |
Chainstay Length | 430 | 430 | 430 | 430 |
Wheelbase | 1,140 | 1,169 | 1,205 | 1,236 |
Rake | 44 | 44 | 44 | 44 |
Trail | 114 | 115 | 114 | 114 |
🐐 Measurements listed in millimeters and degrees
Allied Cycle WorksSep 28, 2022
Payson’s Limited Edition BC40 is an exact replica of his bike, complete with a SRAM Eagle XX1 AXS drivetrain, RockShox SID Ultimate Charger Race Day Remote fork, SID Luxe Ultimate Remote shock, Roval Control SL 29 XD carbon wheels, and Payson’s iconic San Juan custom paint job. .
Payson McElveen, a Texas native, relocated to Durango, Colorado, in 2012. Known as an epicenter of endurance mountain biking, he spends most of his time training there. Payson's BC40 paint scheme was inspired by the infamous and rugged San Juan mountains. A mountain range that forms the southern part of Colorado's Rocky Mountains and is touted as having some of the most diverse landscapes of any mountain range in the U.S. The beautiful but unusual hues created by the distinct geology of the San Juans influenced the colors of this actual one-of-a-kind piece of art on two wheels. When Payson first moved there, he found the mountain range incredibly intimidating, but it was the challenging terrain he needed to reach his potential as an athlete. "They've taught me enormous amounts about myself as an athlete and person. It's extraordinary to have those mountains and years of hard work reflected in this new mountain bike," said Payson.
Over two years in the making, the BC40 was designed for speed, agility, and beauty, painstakingly tested and refined on the iconic singletrack in our backyard, and made entirely here in the United States, by us, with unparalleled precision and passion. Inspired by the legendary Back 40 trail system. Meet the new BC40, a thoughtfully engineered modern cross-country machine mixed with an all-day trail sled. A plush 120mm of front and rear travel combined with a second-to-none pedaling platform and progressive geometry delivers precise speed, handling, and tracking for the needs of the modern trail shredder.
