Compare: 2012 Trek Madone 5.2 H2 (Compact) E

Bikes up to 60% offWe monitor over 40,000 bikes daily to find the best prices

Bike Comparison

Only show differences

	Madone 5.2 H2 (Compact) E2012 Trek	Recommended

MSRP
Where to Buy	— $1 At
Category	Aero
	5.3
Frame	Carbon
	Carbon
Wheels	Aluminum
Wheel Size	700c
	Shimano Ultegra Rim


	Ultegra
Drivetrain	2 × 10
Brand Site
Summary	The Trek Madone 5.2 H2 (Compact) E is a carbon frame aero bike with high-end components and shimano ultegra rim brakes.

Ask 99 Spokes

Want to ask an actual human?

Get free advice from a Gear Advisor at Jenson USA

Similar Bikes

Insights

Gear Range

A bike with lower gearing will be easier to ride up steep hills, while a higher top end means it will pedal faster down hills.

Lowest gear

(climbing)

39 mph

Madone 5.2 H2 (Compact) E

Highest gear

(descending)

Geometry

Specs

	Madone 5.2 H2 (Compact) E2012 Trek

Frame	500 Series OCLV Carbon, E2, BB90, internal cable routing, DuoTrap compatible BB Standard: BB90, 90.5mm, Press Fit
Fork	Bontrager Race X Lite w/E2 carbon steerer, carbon crown & legs
Bottom Bracket	BB90, 90.5mm, press-fit
Headset	Integrated, cartridge bearings, sealed, alloy, 1-1/8" top, 1.5" bottom
Stem	Bontrager Race X Lite, 7 degree, 31.8mm
Handlebar	Bontrager Race Blade VR-C, 31.8mm
Saddle	Bontrager Affinity 3, hollow chromoly rails
Seatpost	Bontrager Ride Tuned Carbon seatmast cap, 20mm offset Type: Rigid
Pedals	n/a

Groupset

Rear Derailleur	Shimano Ultegra
Front Derailleur	Shimano Ultegra, braze-on
Crank	Shimano Ultegra, 50/34 (compact)
Shifters	Shimano Ultegra STI, 10 speed
Cassette	Shimano 105 11-28, 10 speed
Brakes	Shimano Ultegra brakes w/Shimano Ultegra STI levers Type: Shimano Ultegra Rim

Wheels

Rims	Bontrager Race
Tires	Bontrager R3, 700x23c
