    Axis FS 102026 Scott
    Recommended
    MSRP
    ($7,802)
    Where to Buy
    —
    $1

    At

    Category
    		Trail, E-Bike
    Weight
    		63.9 lbs
    6.1
    Frame
    		Aluminum
    		Fox AWL
    		Fox
    Wheels
    		Aluminum
    Wheel Size
    		29″
    		Magura Hydraulic Disc
    		Bosch 600W 85Nm mid-drive
    		800Wh
    		XT
    Drivetrain
    		1 × 12
    Suspension
    		Full
    Front Travel
    		140mm
    Rear Travel
    		140mm
    Brand Site

    scott-sports.com

    Summary
    		The Scott Axis FS 10 is a 29″ aluminum frame full suspension trail e-bike with high-end components.

    Ask 99 Spokes

    Want to ask an actual human?

    Get free advice from an Upway E-bike Expert

    Shop with an Expert
    Similar Bikes
    Insights
    Ride Feel

    Based on frame geometry and build specs.

    Terrain
    easyextreme
    Handling
    nimblestable
    Axis FS 10
    Other Trail bikes
    Gear Range

    A bike with lower gearing will be easier to ride up steep hills, while a higher top end means it will pedal faster down hills.

    Lowest gear

    (climbing)

    31 mph

    Axis FS 10

    Highest gear

    (descending)

    Spec Level

    Based on build material and quality level of the frame, fork, wheelset, groupset, suspension system, and more.

    Geometry
    Specs
    Axis FS 102026 Scott
    Frame

    Alloy S-XL=29"; Integrated Suspension Technology; Virtual 4 Link kinematic, Adjustable head angle; Syncros Cable Integration System; Bosch Smart System, UDH Interface, 12x148mm with 55mm Chainline, Bosch PowerMore Ready

    BB Standard: Bosch, Press Fit

    Hanger Standard: UDH

    Color: Martin Green

    Fork

    FOX AWL 34, Grip Remote Damper 3P, 4QR Axle 15x110mm axle; 44mm offset, tapered steerer, 140mm travel

    Travel: 140mm

    Spring Type: Air

    Shock

    FOX Float eRIDE 185x47; 5mm, 3P, Remote Ready, 140mm Travel

    Travel: 140mm

    Bottom Bracket

    Bosch, press-fit

    Headset

    Syncros - Acros Angle adjust & Cable Routing HS System; Stainless, +-0.6° head angle adjustment; ZS56/28.6 – ZS56/40 MTB

    Handlebar

    Syncros Forged Alloy Combo 680mm, Back Sweep 9°, Up Sweep 8°, 70mm, with front Light mount and Kiox 300 mount

    Saddle

    Syncros Tofino E 2.0

    Seatpost

    Syncros Duncan Dropper Post 2.5; 31.6mm, S&M 361mm, L&XL 403mm

    Type: Dropper

    Pedals

    VP VPE-506

    Groupset
    Rear Derailleur

    Shimano XT RD M8100SGS 12 Speed

    Front Derailleur

    SCOTT Chainguide

    Crank

    FSA CK-745 165mm

    Shifters

    Shimano XT SL-M8100IR

    Cassette

    Shimano CS-M8100-12 10-51T

    Chain

    KMC E12S

    Brakes

    Magura MTC Allroad Disc Brakes, Bosch ABS Trail

    Type: Magura Hydraulic Disc

    Wheels
    Rims

    Syncros MD30, 32H, 30mm, Pin Joint; Tubeless ready

    Spokes

    Sapim double butted

    Front Hub

    Formula CL-811, 15x110mm

    Rear Hub

    Formula CL-148M, Boost 12x148mm

    Tires

    Front: Schwalbe Advancer 60-622 Wired, Rear: Schwalbe Advancer 60-622 Wired

    Disc Rotors

    Front: MDR-C CL 203mm, Rear: MDR-C CL 203mm

    Electric Components
    Motor

    Bosch Performance Line CX (BDU384Y); EU: 25kmh

    Battery

    PowerTube 800Wh

    Remote

    SCOTT TwinLoc Remote 3P

    Display

    Bosch System Controller; Kiox 300; Mini remote

    Charger

    4A Charger

    Accessories
    Lights

    Lezyne Fusion E550SM front light; Rear Supernova Taillight

    Racks

    Racktime SnapIt 2.0 15KG
