    BIG.TRAIL 2002022 Merida
    Recommended
    MSRP
    ($998)
    Where to Buy
    —
    $1

    At

    Category
    		Trail
    Weight
    		31.4 lbs
    4.0
    Frame
    		Aluminum
    		Suntour XCM
    Wheels
    		Aluminum
    Wheel Size
    		29″
    		Tektro Hydraulic Disc
    		Deore
    Drivetrain
    		1 × 10
    Suspension
    		Hardtail
    Front Travel
    		120mm
    Brand Site

    merida-bikes.com

    Summary
    		The Merida BIG.TRAIL 200 is a 29″ aluminum frame hardtail trail bike with upper mid-range components.

    Ask 99 Spokes

    Want to ask an actual human?

    Get free advice from a Gear Advisor at Jenson USA

    Text a Gear Advisor
    Similar Bikes
    Insights
    Ride Feel

    Based on frame geometry and build specs.

    Terrain
    easyextreme
    Handling
    nimblestable
    BIG.TRAIL 200
    Other Trail bikes
    Gear Range

    A bike with lower gearing will be easier to ride up steep hills, while a higher top end means it will pedal faster down hills.

    Lowest gear

    (climbing)

    25 mph

    BIG.TRAIL 200

    Highest gear

    (descending)

    Spec Level

    Based on build material and quality level of the frame, fork, wheelset, groupset, suspension system, and more.

    Geometry
    Specs
    BIG.TRAIL 2002022 Merida
    Frame

    BIG.TRAIL TFS, material: aluminium, 29x2.5" max. wheelsize, 148x12mm axle standard, BSA bottom bracket standard

    BB Standard: BSA, 73mm, Threaded

    Fork

    SR Suntour XCM32 DS, Coil, 120mm suspension travel, Lockout, 46mm fork offset, 29x2.4" max. wheelsize

    Travel: 120mm

    Spring Type: Coil

    Bottom Bracket

    BSA, 73mm, threaded

    Headset

    MERIDA M4455

    Handlebar

    MERIDA EXPERT CC, material: aluminium, 740mm width, 10mm rise

    Saddle

    MERIDA COMP SL, V-mount

    Seatpost

    MERIDA COMP CC, material: aluminium, 30.9mm diameter, 0mm setback

    Type: Rigid

    Pedals

    VP VPE-891

    Groupset
    Rear Derailleur

    Shimano Deore M5120 Shadow+, SGS

    Crank

    Shimano Deore M5100, 32 teeth, 170 mm-S, 175 mm-M up

    Shifters

    Shimano Deore M4100

    Cassette

    Shimano Deore M4100, 11-46 teeth, 10 speed

    Chain

    KMC X10

    Brakes

    Tektro M275, 2 piston

    Type: Tektro Hydraulic Disc

    Wheels
    Rims

    MERIDA COMP TR, 29mm inner width, material: aluminium, Tubeless ready (tubeless tape and valves not included)

    Spokes

    Black stainless

    Front Hub

    Shimano MT400-B, 100x15mm width front hub, 32 spoke holes, Centerlock

    Rear Hub

    Shimano MT400-B, 148x12mm width rear hub, 32 spoke holes, Centerlock

    Tires

    Kenda Regolith, 29x2.4", wire

    Disc Rotors

    Shimano RT10, 180 mm
