2019 Raleigh

Redux iE Step Thru

A 650b aluminum frame commuter e-bike with upper mid-range components and hydraulic disc brakes.
Compare the full range

MSRP$3,499
FrameAluminum
SuspensionRigid
ForkAluminum
Wheels650b Aluminum
Drivetrain1 × 10
GroupsetDeore, FSA
MotorBosch 350W 63Nm mid-drive
BatteryBosch 500Wh
BrakesHydraulic Disc
Where to Buy
Similar Bikes

For This Bike

Accessories
Top Comparison
Reviews
Electric Bike Review
Raleigh Redux iE Review

Nov 2019

Price: $3499.00 | Model Year: 2019 | A sleek, purpose built high speed ebike, with excellent weight distribution and smooth power transfer, 10-speed drivetrain and powerful hydraulic disc brakes to match

Observations
  • A sleek, purpose built high speed ebike, with excellent weight distribution and smooth power transfer, 10-speed drivetrain and powerful hydraulic disc brakes to match

  • Stiff thru-axles and a rigid Aluminum alloy fork are balanced out by fatter 2.0" Schwalbe tires, great for comfort and varied urban terrain

  • Available in three frame sizes for improved fit, durable chain-guide doubles as a bash guard, grippy pedals, locking grips and adjustable kickstand, great electric system and great display

  • A little more ridged from last years model, however this can improve responsiveness, connecting you to the bike's agile experience

Read Review

Geometry
99 Spokes on YouTube99 Spokes on YouTube
Specs
Build
Frame

Formed 6061 T6 Oversize Aluminum Alloy, Thru Axle Dropout, Disc Brake Specific, Semi Integrated Battery

BB StandardBosch, Press Fit

Fork

Formed 6061 T6 w/ Integrated Crown, Disc Brake, Thru Axle

Bottom Bracket

Bosch, press-fit

Headset

Integrated, Sealed Bearing

Stem

Raleigh Aluminum Alloy, 3d Forged

Handlebar

Raleigh Aluminum Alloy

Saddle

Raleigh Custom Ergo Performance

Seatpost

Raleigh Aluminum Alloy, Forged Head, 350mm

TypeRigid

Pedals

Shoe Friendly Urban Design, Resin Body

Grips

Raleigh Ergo Comfort Control

Groupset
Rear Derailleur

Shimano Deore M610, SGS

Crank

FSA Forged Alloy for Bosch System

Shifters

Shimano Deore SL-M6000, 10 Speed

Cassette

FSA Forged Spider, 20 tooth w/chainguard, steel

Chain

KMC x10e EPT, Ebike Specific

Brakes

Tektro M735, 4 Piston Front 180mm Rotor, 2 Piston Rear 160mm Rotor

TypeHydraulic Disc

Brake Levers

Tektro M735, 2 Finger Lever

Wheels
Rims

Aluminium 27.5", Black Annodized, 25mm ID, Disc Specific, 32 Hole

Spokes

Black w/Silver Nipples

Front Hub

Formula, Sealed Bearing, Thru Axle

Rear Hub

Formula, Sealed Bearing, Thru Axle

Tires

27.5" x 2.4" Schwalbe Super Moto

Electric Components
Motor

Bosch Performance Speed, 350W, 28MPH, Made in EU

Battery

Bosch Powerpack 500Wh, DT Mount

Display

Bosch Kiox On-Board Computer
